COB Downlight-Square (8inch)

CKR030AC/W, CKR050AC/W

COB square downlight has High CRI (over 90Ra) and 97Ra is available for customized order. Multiple downlights can be connected with a simple combination using its bracket so that it can be installed any shape.
Suitable for museum, department store, hotel, office, exhibition, shopping mall, clothing store, restaurant etc.

Option
    선택된 상품의 옵션리스트 입니다.
Total: $ 0
Origin Made in Korea
Certificate KS, Q-Mark
Packing Standard 12 per box, 48.5cm x 49cm x 38.5cm / 12 per box, 48.5cm x 49cm x 38.5cm
Advantages
  • Easy installation, High efficiency, Modern design
  • High Color Rendering Index (Premium High CRI-90Ra)
  • Adjustable beam angle delivers high intensity light beam
  • Suitable for museum, art museum, department store, hotel, gallery, exhibition, store, restaurant etc
Specification
Product Name CKR030AC/W(8inch) CKR050AC/W(8inch)
Power(W) 30 50
Working Voltage(V) AC180-260, 50/60Hz AC180-260, 50/60Hz
Luminous Flux(lm) 2700 / 2300 4700 / 4200
Efficacy(lm/W) Over 95 / 80 Over 100 / 90
Color Temperature(K) 5000 / 3000 5000 / 3000
CRI(Ra) Over 90 Over 90
Power Factor(PF) Over 0.90 (High PF) Over 0.90 (High PF)
Life Span(Normal Temperature and Humid) Over 15000h Over 15000h
Size(mm) 230 x 230 x103 230 x 230 x 103
Aperture(mm) 195 x 195 (±5) 195 x 195 (±5)
Ceiling Thickness(mm) 1~16 1~16
Color BLACK, WHITE BLACK, WHITE
Material PC, AL PC, AL
