COB 100W Lamp(E39)

AAE100ACSH, AAE100BCSH

COB Lamp 100W is of grade 90Ra. Compared to previous metal lamps and mercury lamps, the luminous flux maintenance rate is more than five times longer. So the lifespan is five times longer.The maintenance costs can be reduced. It uses heat pipes to extend the lifespan by more than 50,000 hours.
Suitable for the places with high ceilings, such as the factory, warehouse, warehouse shopping center, gas station.

  • Quantity
Origin Made in Korea
Certificate KS, Q-Mark
Packing Standard 4 per box, 43.9cm x 44cm x 30.6cm
Advantages
  • Energy consumption efficiency level Class-first(80Ra,90Ra)
  • High light efficacy 80Ra - 13000lm / 90Ra - 11500lm
  • High color rendering index 80Ra, 90Ra (metal lamp 65Ra/ mercury lamp 60Ra)
  • Connect heat pipe with heat sink, excellent light radiation
  • Compared with mecal lamp,mercury lamp, it can save over 45~50% energy consumption
  • Using lens can improve light straightness and direct luminance
  • Golden color is available for customized order.
  • Suitable for the places with high ceilings, such as the factory, warehouse, shopping center etc.
Specification
Product Name AAE100ACSH AAE100BCSH
Power (W) 100 100
Working Voltage(V) AC180-260, 50/60Hz AC180-260, 50/60Hz
Luminous Flux(lm) 13000 11500
Efficacy(lm/W) Over 130 Over 115
Color Temperature(K) 5700 5700
Power Factor(PF) Over 0.90 (High PF) Over 0.90 (High PF)
CRI(Ra) Over 80 Over 90
Beam Angle(˚) 80 80
Life Span(Normal Temperature and Humid) Over 50000h Over 50000h
Size(mm) φ180 × 246.2 φ180 × 246.2
Color BLACK BLACK
Material AL, PC, GLASS AL, PC, GLASS
Base E39 E39
