Corner Light (Combined Use for Emergency Power)

PBV025, PBV050

IP65 Corner Light is a hexagonal shape. It can be installed on the ceiling, wall and in corners. Ideally suitable for small places and corner places. It is designed to install for humid and dusty places such as bath, basement warehouse, outdoors, workshop, factory, etc.

  • Quantity
Origin Made in Korea
Certificate KS
Packing Standard 15 per box, 61.5cm x 36cm x 37cm / 9 per box, 122cm x 36.3cm x 23cm
Advantages
  • IP 65, available for outdoor and indoor with high humidity.
  • Especially suitable for small places and corner spaces.
  • As it is a hexagonal type, it can be installed on the ceiling, on the corner and also walls.
Specification
Product Name PBV025 PBV050
Power(W) 25W (Emergency Power: 13W) 50W (Emergency Power: 25W)
Power Factor(PF) Over 0.90 (High PF) Over 0.90 (High PF)
Working Voltage AC180-260, 50/60Hz AC180-260, 50/60Hz
Luminous Flux(lm) 2625 / 2125 (Emergency Power: 1560 / 1300 lm) 5500 / 4500 (Emergency Power: 3000 / 2500 lm)
Efficacy(lm/W) Over 105 / 85 (Emergency Power: 120/ 100 lm/W) Over 110 / 90 (Emergency Power: 120 / 100 lm/W)
Color Temperature(K) 6500 / 2700 6500 / 2700
CRI(Ra) Over 80 Over 80
Size(mm) 594 x 109 x 63.2 1194 x 109 x 63.2
Material PC PC
Color WHITE WHITE
Weight 550g 1KG
IP Grade 65 65
